Yanmar V8

Description: Financing & shipping available. 860_681_3610 SPECIFICATIONS ELECTRICAL SYSTEM Nominal voltage 12 V Battery 12 V / 100 Ah Generator 14 V / 95 A Starter 12 V / 3.5 hp (2.6 kW) Cold-starting aid Glow plugs Lighting system in compliance with US/ISO standards, H7 headlamps. STEERING Articulated, 1 steering cylinder with final positioning damping on both sides, fully hydraulic through Load-Sensing priority valve, quick and easy steering even at engine idle-running speed. Total steering angle 80 deg. LOADER FRAME Loader installation featuring true parallel linkage and hydraulic quick coupler General-purpose bucket (SAE J 742) 1.05 yd3 (0.80 m3 ) Lift capacity at ground level (SAE J 732) 10,800 lbs (48,000 N) Breakout force at bucket edge (SAE J 732) 10,328 lbs (45,900 N) FORK LIFT ATTACHMENT Operating load (SAE J 1197) over the total lift and steering range 2,945 lbs (1,335* kg) Operating load in transport position, above ground level, total steering range 5,512 lbs (2,500* kg) Width of fork carrier 4' 1" (1,240 mm) Length fork tines 4" x 1.8" (100 mm x 45 mm) 3' 6" (1,100 mm) Stability factor 1.25 Load center from fork attachment point 22" (560 mm) OPERATING DATA, STANDARD EQUIPMENT Operating weight (SAE J 1197) 10,802 lbs (4,900 kg) Tipping load, straight at full reach (ISO 14397-1) 8,311 lbs (3,770 kg) Tipping load, articulated at full reach (ISO 14397-1) 7,341 lbs (3,330 kg) Total length, bucket on ground 16' 6" (5,060 mm) Total width 6' 1" (1,850 mm) Turning radius at outside bucket edge 13' 8" (4,160 mm) Wheelbase 6' 9" (2,100 mm) 81 Total height (top of cab) 8' 7" (2,640 mm) POWER TRANSMISSION Hydrostatic drive, closed circuit, independent from loader hydraulics. Perfected driving automatics, automatic optimisation and adjustment of drawbar pull and speed. Hydraulic motor power shift providing two speed ranges. Infinitely variable speed control forward and reverse. 4-wheel drive from reduction gear on rear axle via cardan shaft to front axle. Inching pedal for sensitive driving and stopping at high rpm. 4 speeds: Standard version 0 mph – 12.4 mph S version 0 mph – 22.4 mph AXLES Rigid front axle with 35% limited slip differential. Oscillating rear axle with 35% limited slip differential. Center-mounted disc brake. BRAKES Service brake: Hydraulically actuated center-mounted disc brake, acting on all 4 wheels via 4-wheel drive Auxiliary brake: Hydrostatic drive provides dynamic braking Parking brake: Mechanically actuated center-mounted disc brake on front axle FLUID CAPACITIES Fuel tank 20 gal (75 l) Hydraulic system (incl. tank) 15 gal (55 l) TIRES Standard 405/70 R 18 SPT 9 Dunlop HYDRAULIC SYSTEM Max. pump capacity 17 gpm (65 l/min) Max. working pressure 3,634 psi (250 bar) Control unit: Proportional hydraulic valve with 3 control circuits, supplying work functions “Lift/Lowerâ€, “Dump/Tilt-back with high-speed control†and “3rd control circuit (1st additional control circuit)â€. Simultaneous, independent control of all movements. Hydraulic cylinders: 1 lifting cylinder, 1 tilt cylinder, all dual-action The thermostatically controlled oil circuit ensures that the oil temperature is promptly reached and avoids overheating. Return filter installed in hydraulic tank allows for eco-friendly replacement of filter elements. Fingertip control for 3rd control circuit, electro-proportional, oil flow limitation via machine function display, continuous operation. Installation on loader frame incl. couplings. Hydraulically switchable float position by overdriving the pressure point “Lower†on the joystick, electrically switchable continuous operation function. Single, four-way control lever (joystick) with integrated direction-of-travel switch and switch for additional control circuit. ENGINE Manufacturer, model YANMAR 4TNV98C Type Diesel engine with intercooler, exhaust-gas optimised, EPA Tier 4 Final / EC stage 5 Combustion
