Geotec ROTOMAX Li

Prix (hors TVA)

Prix non renseigné

FavoriteFavoris
sharePartager
Save searchSauvegarder la recherche
Imprimer

INFO

Catégorie
Foreuse de puits d'eau
Marque / Modèle
Geotec ROTOMAX Li
Année d'immatriculation
2022
Options supplémentaires
Neuf
Emplacement
Nordkirchen
Pays
Allemagne
Note globale
1
2
3
4
5
Mascus ID
B88F05AC

CARACTÉRISTIQUES

Dernière révision
2022
Contrat d’entretien
Oui
Moteur
136KM
Fabricant Moteur
PERKINS
Catégorie d'émission
Stage V
Circuit de refroidissement
Eau
Mécanisme d'alimentation
Cylindre
Heures de service
0
Heures de percussion
0
Manipulateur de tiges
GEOTEC
Marque du mécanisme d'alimentation
GEOTEC
Chenilles
GEOTEC
Type de transporteur
À chenilles
Informations / condition de Garantie
1000 Hours / 1 Year
Poids du volume de transport
6 000 kg
Dimensions du volume de transport (L x l x H)
4000 x 1600 x 2400 mm
État neuf pneus avant
100
État neuf pneus arrière
100
Conditions de livraison
EXW
Autres informations
EVERY MACHINE LEAVING OUR FACTORY - HAS DIFFERENT EQUIPMENT CONFIGURATIONS! BELOW YOU WILL FIND AN EXAMPLE OFFER! IF YOU HAVE QUESTION, PLEASE CONTACT US! WE ALSO HELP IN FINANCING! Drive: 100 kW (136 HP) 4-cylinder turbo diesel engine with Stage 5 and direct drive hydraulic pumps, pressure filter, oil cooler, bypass filter for the hydraulic circuit and AdBlue. Hydraulic system: Dual-circuit, load-independent primary hydraulics (1x load-responsive, 1x permanent), proportional, partially direct or remote controlled Control Valves: Main Control Valves - Auxiliary control blocks partially controlled manually Pressure indications: system pressure of the hydraulic circuits, supply from the purge pressure Drive type: gear with feed, disc brake Speed: Normal and rapid feed (2 speeds) (Max. 5 possible) Drilling pressure: max. 2,500 kg Lifting: max. 9,000 kg Stroke: 4,200 mm Drilling gear: Vibration-stable drilling gear with proportional hydraulic motor. Speed ​​range: 0 - 350 min-1 Torque range: 0 - 10,000 Nm Speeds and torques are set with the potentiometer on the control panel. Drilling pipes; GT95 (Customization possible) Maximum mounting diameter on the head: 178 mm (with more adapter) Grease lubrication system drilling gear (active cylinders) Clamping head Articulated rollers Sideshift Middle Pipe Clamp: Clamping range: Ø80 mm - Ø324 mm Swivel angle: 30 ° Breakaway torque: 20 kN Lifting force: 120 kN Lifting height: 400 mm Lubrication: Central lubrication beam Specifications are subject to change. Each machine is individually equipped.Plus de critères

GEOTEC BOHRTECHNIK

Aspastrasse 26 59394 Nordkirchen Nordrhein-Westfalen Allemagne
