Komatsu PC 50 MR
Prix (hors TVA)
Imprimer
INFO
Catégorie
Mini pelle < 7t
Marque / Modèle
Komatsu PC 50 MR
Année d'immatriculation
2022
Heures d'utilisation
845 h
Pays
Chine
Note globale
1
2
3
4
5
Mascus ID
D2EF9A11
PRIX
Choisir une devise
CARACTÉRISTIQUES
Type
Diesel
Dernière révision
2025-08-20
Nombre de propriétaires précédents
1
Condition du train de roulement
98%
Poids brut
5 040 kg
Catégorie d'émission
Stage V
Largeur de chenille
600 mm
Capacité du godet
0,20 m3
Dimensions du volume de transport (L x l x H)
5590 x 1960 x 2660 mm
Couleur d'origine
original
Moteur
original
Rendement moteur
29,4 kW (40,0 CV)
Fabricant Moteur
original
Informations / condition de Garantie
1 year
Conditions de livraison
FCA, FOB, CIF, EXW
Certificats
EPA, CE
Autres accessoires
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Nina
Whatsapp: +86 18055199047
Mobile:+86 18055199047
Wechat:18055199047
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs
Accessoires
Climatisation
Seau squelette
Commande joystick
Godet rétro standard
Contrôle de profondeur
Autres informations
Basic Parameters:
Operating Weight: 5040kg
Standard Bucket Capacity: 0.2m³
Rated Power: 29.4kW
Performance Parameters:
Travel Speed: 4.3/2.6km/h
Maximum Traction Force: 4280Kgf
Swing Speed: 9rpm
Bucket Digging Force: 3980kg
Arm Digging Force: 2440kg
Ground Pressure: 0.32kg/cm²
Engine Parameters:
Model: 4D88E-5
Rated Speed: 2350rpm
Engine Type: 4-stroke water-cooled direct injection
Displacement: 2.189L
Hydraulic System Parameters:
System Type: Pressure-compensated CLSS system
Main Pump Type: Variable displacement piston pump × 2 + Gear pump × 1
Maximum Flow Rate: 51×2 + 31L/min
Working Device Hydraulic Circuit Pressure: 270Kmf/cm²
Working Range Parameters:
Maximum Digging Depth: 3800mm
Maximum Dumping Height: 4160mm
Maximum Digging Distance: 5850mm
Maximum Digging Radius: 6220mm
Tank Capacity Parameters:
Fuel Tank Capacity: 65L
Hydraulic Oil Tank Capacity: 55L
Overall Dimension Parameters:
Overall Length: 5590mm
Overall Width: 1960mm
Overall Height: 2660mm
Minimum Ground Clearance: 320mm
Tail Swing Radius: 1060mm
