Grundfos UPS50-60F

3-Speed Circulator Pump UPS50-60F Title: 3-Speed Circulator Pump UPS50-60F SKU: 137256 Model: UPS50-60F Condition: Used S/N: 97523134 GeneralHorsepower:0.34hp GPM:124 Pump Material:Cast Iron ElectricalVoltage:115volts Phase:3-phase Dimensions: 28.00 (H) x 19.00 (W) x 59.00 (L) inches Technical Speed No.: 3 Rated Flow: 62 US gpm Max/ Flow: 124 US gpm Rated Head: 12.74 ft Max. Head: 21.33 ft Installation Maximum ambient temperature: 104 °F Ambient max at 176°F liquid: 176 °F Maximum operating pressure: 145.04 psi Type of connection : 4-BOLT FLANGE, C.I. Flange Pipe connection: 4 - Bolt Flange Pressure rating for connection: PN 10 Port-to-port length: 8 9/16 in Liquid Pumped liquid: Water Liquid temperature range: 35.6 .. 230 °F Selected liquid temperature: 140 °F Density: 61.35 lb/ft Electrical data Power input in speed 1: 0.3487 HP Power input in speed 2: 350 W Max. power input: 395 W Main frequency: 60 Hz Rated voltage: 1 x 115 V Current in speed 1: 2.7 A Current in speed 2: 3.4 A Current in speed 3 : 3.6 A Capacitor size - run: 40 F/180 V Number of poles: 2 Insulation class (IEC 85): H Thermal protect: internal
